Disassembling and assembling bale twister Disassembling bale twister from wrapping table NOTE! It is recommended to use a block and tackle to move heavy parts.
K
– Switch on tractor engine. – Lower wrapping table: 4
• Set three-way valve to position II (refer to decal). • Turn emergency stop switch (K) to release wrapper from its safety position. • Press "Raise/lower wrapping table" button (P) in Uniwrap control box: that triggers "Raise/lower wrapping table" function.
P
• Press key (O) to lower wrapping table until bale twister disengages from holders. O
DANGER! 5
Risk of fatal injury. If bale twister falls accidentally, this can cause serious injury.
☞ There must be no one in bale twister swivel area when it is triggered by control box. • Press emergency stop switch to clamp wrapper and make it safe. – Switch off tractor engine. – Remove ignition key. (Fig. 5, 6)
98
BA VB - Rollant 255 Uniwrap - 0299 436.2
