OPERATING INSTRUCTIONS 6015 / RH40E Operation A loss of performance and higher wear must be accepted when the machine works in an inclined position, e.g. when building a ramp or when swinging uphill. For the building of ramps, the values specified in the table "Maximum inclinations during working operations" may be exceeded. In this case, however, a reduced service life of the components can be expected. During downtimes, the machine must be parked in such a way that its inclination does not exceed 3° / 5.2 %
MAXIMUM MACHINE INCLINATIONS, INFORMATION
The machine must not exceed the inclinations indicated for working, travelling and servicing operations and during downtimes. The values specified in the tables below are valid for all types of working equipment. If the maximum inclinations are exceeded, there is a risk of severe damage to the engine due to insufficient lubrication. In the event of extreme inclinations the machine can topple over. The working performance of the machine is especially economical when the machine stands on firm and level ground. Maximum machine inclinations during working operations:
forward inclination
rearward inclination
side inclination
5° / 8.7%
5° / 8.7%
5° / 8.7%
Maximum machine inclinations during travelling: Type
Engine
forward deg / %
rearward deg / %
side deg / %
Type
Engine
forward deg / %
rearward deg / %
side deg / %
RH40E QSK19 30° / 57.7% 30° / 57.7% 30° / 57.7%
RH170B KTA38 30° / 57.7% 30° / 57.7% 30° / 57.7%
(=6015)
(=6040)
C18
30° / 57.7% 30° / 57.7% 30° / 57.7%
C32
30° / 57.7% 30° / 57.7% 30° / 57.7%
RH200 KTTA38 30° / 57.7% 30° / 57.7% 30° / 57.7% RH90C
C18
30° / 57.7% 30° / 57.7% 30° / 57.7%
(=6050) K1500E 30° / 57.7% 30° / 57.7% 30° / 57.7%
(=6018)
QSK38 25° / 46.6% 25° / 46.6% 25° / 46.6%
RH120E QSK19 30° / 57.7% 30° / 57.7% 30° / 57.7%
RH340B QSK45 20° / 36.4% 20° / 36.4% 20° / 36.4%
(=6030)
C18
30° / 57.7% 30° / 57.7% 30° / 57.7%
(=6060) C3512C 24° / 44.5% 24° / 44.5% 24° / 44.5%
C27
25° / 46.6% 25° / 46.6% 25° / 46.6%
RH400 QSK60 20° / 36.4% 20° / 36.4% 20° / 36.4%
Maximum machine inclinations during maintenance operations:
forward inclination
rearward inclination
side inclination
0° - 2° / 3.4%
0° - 2° / 3.4%
0° - 2° / 3.4%
