OPERATING INSTRUCTIONS 6015 / RH40E Operation VENTILATION AND HEATING
Air conditioner (optional)
Ventilation (fresh air)
The control elements of the air cond. are installed under the ceiling of the driver's cab (Fig. 2-46). The desired temperature is adjusted with control knob (1). The desired blower intensity level / amount of air is selected with control knob (2). For more information, please refer to the air conditioner manual of the manufacturer.
Fig. 2-44:
When the engine is stationary, turn keyoperated switch (72, Fig. 2-44:) to position 1 Slide heating control lever (91, Fig. 2-45:) backwards (heating power = 0). Turn rotary switch (60, Fig. 2-44:) to the desired fan intensity (steps 1 - 3).
Adjusting the heating performance Slide lever (91, Fig. 2-45:) forwards depending on the heating performance desired. The foremost position gives maximum heating power. If greater amounts of warm air are needed, switch on the fan with rotary switch (60, Fig. 2-44:).
Fig. 2-45:
2-46
Fig. 2-46
Auxiliary heating (optional) Switch ON / OFF auxiliary heating with switch (89, Fig. 2-47). When switched ON, indicator lamp (90) lits. Additional information can be found in the manufacturers instruction manual.
Fig. 2-47
BA RH40E(3 725 069.00)-EN
