OPERATING INSTRUCTIONS 6015 / RH40E Operation Filling in fuel Unscrew cap of filler tube (2, Fig. 2-27:). Fill in fuel through the filter sieve in the filler tube. Do not remove the sieve.
Refuelling with the refuelling system (optional) The refuelling system (1, Fig. 2-29:) is installed besides the step-ladder.
Fig. 2-29: Fig. 2-27:
The refuelling system consists of an electrical pump,filling hose, switch box (2, Fig. 2-30:) and key-switch (3).
Quick refuelling (optional) The express coupling (1, Fig. 2-28:) for quick refulling is located behind the step-ladder.
Fig. 2-30:
Fig. 2-28:
For filling in fuel, unscrew the cap of the express coupling.
Check before refuelling that the earthing strap (4, Fig. 2-30:) is attached to the chassis. Sparking caused by static or electric charges may set fuel on fire.
Attach express coupling of filling hose from the service vehicle to the express coupling. Fill in fuel. When the fuel tank is filled, take off filling hose and refit cap on the express coupling.
