OPERATING INSTRUCTIONS 6015 / RH40E Operation Fig. 2-22: No. 51
Element Switch
52 53
Momentary contact switch Switch
54
Switch
55
Switch
56 57
Switch Switch
Speed reduction
58
Switch
Greasing system
59 60
Display Rotary switch
Operating hours Fan, air conditioner
Preheating system engine and hydraulic oil (optional) Engine monitor Floodlamps on working equipment (optional) Engine monitor
Preheating system fuel (optional)
BA RH40E(3 725 069.00)-EN
Function Switch preheating system for engine and hydraulic oil ON/OFF. When switched on, indicator lamp (24) lits. Diagnose ON/OFF
Symbol
Floodlamps on the working equipment ON / OFF Listing of fault codes, see warning lamps (6 and 7) (Increment – next fault) (Decrement – previous fault) Switch preheating system for fuel ON/OFF. When switched on, indicator lamp (31) lits. Free for optional equipment to the left: normal operation of automatic speed reduction of diesel engine; activated during working pauses to the right: automatic speed reduction off Starts an additional greasing intervall. Length of interval is programmed in the controller. Not in use 3-stage regulation of air flow.
