OPERATING INSTRUCTIONS 6015 / RH40E Operation Fig. 2-20: No. Element 26 Warning lamp
Hydraulic oil filter
27
Indicator lamp
Idle-Auto
28
Warning lamp
Superstructure holding brake
Symbol Function Lit when the flow resistance in the hydraulic return-flow filters is too high. Replace filter elements when this warning lamp does not go out with the oil at operating temperature Lit when the automatic speed reduction function is activated (speed reduced to idling when the pilot control valves remain inactivated for abt. 10 seconds). Lit when the holding brake is applied. The holding brake is automatically applied when the superstructure is stationary.
29 30
Indicator lamp
Lubrication ON
31
Indicator lamp
32
Warning lamp
Preheating system fuel (optional) Hydraulic reservoir
33
Indicator lamp
Pilot control
34 35
BA RH40E(3 725 069.00)-EN
The holding brake is automatically released when the "Slewing" function is active.
Free for optional equipment Lit when the lubricating system is on and in the event of a malfunction (see "Central lubricating system") Lit when the preheating system is switched on (switch 55). Lit when the shut-off valve at the hydraulic reservoir is closed. The engine cannot be started when the shut-off valve is closed. Closing the valve while the engine is running stops the engine. Lit when the pilot control is active. see also pushbutton (85) Free for optional equipment Free for optional equipment
2-25
