OPERATING INSTRUCTIONS 6015 / RH40E Operation Cab interior lamp
Windscreen washer
The interior lamp is switched on and off with switch (1, Fig. 2-9:).
The reservoir of the windscreen washing system (1, Fig. 2-10:) is located in the behind the cover (1, Fig. 2-11:). Remove cover (1). For the reservoir (1, Fig. 2-10:) capacity refer to the "Refilling quantities - Other" table.
Fig. 2-9:
Switch position
0 - lamp off, 1 – lamp on.
The interior lamp can be used even if the electrical system is switched off.
Fig. 2-10:
Therefore, switch off the interior lamp when leaving the machine. The batteries may be discharged if the interior lamp is left on for prolonged periods.
Fig. 2-11:
BA RH40E(3 725 069.00)-EN
2-13
