OPERATING INSTRUCTIONS 6015 / RH40E Repair work hosepipes, filling station; idlers, support and track rollers.
Further hazardous substances
Batteries contain lead and acid.
Have the refrigerant (R134A) sucked out of the air conditioner system.
Grease from the central lubricating system, grease drum, piping and hosepipes, distributors, filling station; grease accumulations in bearings of the working equipment, grease filling in the swing ring, grease filling in track and support rollers as well as in idlers.
Electronic modules are located in switch cabinets of the cab module, the engine module, the control column.
Pressure accumulators contain nitrogen under high pressure and possibly remainders of hydraulic oil.
Lamps of Xenon working lights contain mercury. The required electronic control circuits are integrated in the housings of the working lights.
The fluorescent lamps of the maintenance lighting (discharge types) contain mercury.
Insulating material of cables can contain PVC.
The fire extinguishing system (if installed) contains trigger charges (ATTENTION, explosion risk) on the extinguishing agent containers. Pressure accumulators, extinguishing gas and extinguishing powder. For more detailed information please refer to the manufacturer's safety datasheets.
