OPERATING INSTRUCTIONS 6015 / RH40E Inspection and servicing Filling in new oil / Topping up
Gearbox venting
The gearbox is vented through breather filter (2, Fig. 3-82:). Clean breather filter in accordance with the servicing plan.
Unscrew plug (4, Fig. 3-82:) and fill in new oil.
Check oil level with dipstick (1, Fig. 3-82:). Screw in plug (4) again.
Unscrew breather filter (2), clean in white spirit or paraffin oil and blow dry with compressed air. Screw breather filter (2) back in place.
Output pinion Grease bearing regulary. Fill in approximate 50 cm3 / 1,7 oz grease through grease nipple (5, Fig. 3-83:) by means of a hand grease pump.
Fig. 3-82:
Fig. 3-83:
BA RH40E(3 725 069.00)-EN
3-81
