OPERATING INSTRUCTIONS 6015 / RH40E Inspection and servicing Gearbox venting
Pre-chamber
The gearbox is vented through breather filter (2, Fig. 3-78:).
The pre-chambers are vented through breather filter (2, Fig. 3-79:).
Clean breather filter in accordance with the servicing plan.
Clean breather filter in accordance with the servicing plan.
Unscrew breather filter, clean in white spirit or paraffin oil and blow dry with compressed air.
Unscrew breather filter, clean in white spirit or paraffin oil and blow dry with compressed air.
Screw breather filter back in place.
Screw breather filter back in place.
Fig. 3-78:
BA RH40E(3 725 069.00)-EN
Fig. 3-79:
3-79
