OPERATING INSTRUCTIONS 6015 / RH40E Inspection and servicing Changing the gearbox oil
Pre-chamber
Draining off oil
Draining off oil
Prepare a collecting recipient for used oil.
Prepare a collecting recipient for used oil.
Choose the required capacity in accordance with the "Refilling quantities - Oil" table.
Choose the required capacity in accordance with the "Refilling quantities - Oil" table.
Unscrew plug (3, Fig. 3-76:) and drain off oil.
Unscrew plug (7, Fig. 3-76:) and drain off oil.
Screwing out breather filter (2) facilitates draining off the used oil. Plug (3) is accessible from the bottom.
Plug (7) is accessible from the bottom.
Screw plug (3) back in place.
Filling in oil
Screw plug (7) back in place.
Unscrew breather filter (2, Fig. 3-77). Fill in new oil through opening of breather filter (2). The oil level should reach up at least to the middle of the inspection glas (3).
Fig. 3-76:
Filling in oil Unscrew breather filter (2, Fig. 3-76:). Fill in new oil through opening of breather filter (2). After oil changes, plug (3) must be tightened beforehand.
Fig. 3-77
Check oil level with dipstick (1). Oil can also be filled in through the opening of the breather filter (2, Fig. 3-77).
3-78
BA RH40E(3 725 069.00)-EN
