OPERATING INSTRUCTIONS 6015 / RH40E Inspection and servicing Replacing a defective Xenon-lamp Read and observe the: „Xenon floodlight projector, replacing the lamp, Safety instructions“. Switch off the projector, shut off the engine and cut out the battery main switch. Wait until the housing of the floodlight projector has cooled down. Withdraw the power supply connector from the projector.
Fig. 3-42
Remove four screws (1, Fig. 3-42) and withdraw the reflector (2) from the projector housing. Withdraw connector (Fig. 3-43) from Xenon lamp socket. Unscrew Xenon lamp holding clamp (Fig. 3-44). Remove the defective Xenon lamp and replace by a new one. Do not touch the glass bulb of the lamp. Reinstall the new lamp. Screw lamp holding clamp back in place. Plug the power supply connector onto the lamp. Re-assemble the housing.
Fig. 3-43
Fig. 3-44
3-58
BA RH40E(3 725 069.00)-EN
