OPERATING INSTRUCTIONS 6015 / RH40E Inspection and servicing
Filling quantities - oil Location
Filling quantities in litres
Oil
gal
Drive engine - without filter change
app. 60
app. 15.85
- with filter change
app. 66
app. 17.45
Hydraulic oil system at oil change
app. 1700
app. 449
- oil reservoir
app. 1300
app. 343
Pump transfer gearbox
app. 15
app. 3.96
pre-chamber (working pumps)
2 x app. 1.4
2 x app. 0.37
pre-chamber (hydraulic pumps)
1 x app. 0.2
1 x app. 0.05
Slewing gearbox
app. 14
app. 3.7
Travel gearbox
2 x app. 18
2 x app. 4.75
I I I II II III.a III.b III.c
Filling quantities - other Location
Filling quantities in litres
gal
Cooling system - engine
app. 115
app. 30.4
Fuel tank
app. 1300
app. 343
Screen washer
app. 13
app. 3.4
3-28
BA RH40E(3 725 069.00)-EN
