TRANSMISSION AND CONVERTER OIL AND FILTER CHANGE OIL AND FILTER CHANGE INTERVAL ------------- 1000 Hours 1. Remove the drain plug from the transmission.
Figure 42
Figure 43 ·
2. Remove the transmission oil strainer, Figure 42 and clean with mineral spirits using a soft bristle brush. Reinstall clean strainer in transmission 3. Remove the cover clamp, Figure 44, cover and relief valve, "O" ring and element. 4. Remove the four clamp bolts and nuts, Figure 43. Filter body is .then positioned for easy draining and cleaning.
t'n
COVER AND RELIEF V A L V E - - - - ' T '
ASSEMBLY~~
ELEMENT---------~~~
g
"O"RING----0
NOT/ Always install a new "O" ring whenever the cover is removed.
~ BODY AND
5. Flush out the filter body with clean fuel before installing the new filter element.
~·
COVER CLAMP
CLAMP
. '-.,
ASSEMBLY'-......~-.· ••• ~
Figure 44
58
