4A - INFORMATION CENTER
21C SERIE WHEEL LOADERS TRAINING MANUAL PROGRAMMING THE INFORMATION CENTER
Display field numbers and description Field number Item StatusIndications possibles 100 Transmission ECM (EST 37) 62101 - 72101 - 82101 - 92101 Identification number 101
Transmission ECM (EST 37) Identification number
62101 - 72101 - 82101 - 92101
102
Transmission ECM Identification Lock and Reprogram Set
000: 001:
103
Transmission ECM Identification Reprogramming result
0 - - = No data received from Transmission ECM 1 - - = Data received from Transmission ECM 100 = TECM Identification Numbers are the same. 101 = TECM Identification Numbers are different 110 = TECM ID.N have been successfully reprogrammed. 111 111 = TECM ID.Nrs not present as received
104 to 113
Reserved for future machine information
114 115
Beginning numbers of Case Cluster Part Number Remaining numbers of Case Cluster Part Number
116
Cluster production date code (yr ñ day) Example: 96 135
117 to 120
Reserved for future use
130 131 to 139
Tire Size Calibration for speedometer Dedicated to tire calibration numbers
140 to 160
Reserved for future use
171 to 190
Resettable Fault Code #1 Through Fault Code #10172, 174, 176, 178, 180, 182, 184, 186, 188, 190Hour Code #1 Through Hour Code #10. Hour Codes Follow Resettable Fault Codes Respectively. Input analogue data read by the microprocessor. Voltages read by the microprocessor will not exceed 5 volts When “13” is entered in this location, the analogue data inputs to the microprocessor will be displayed in location 000 to location 015. It is read as 0 = 0 volts and 1023 = 5 volts. When the Information Center is turned off, location 197 will reset back to 0 and normal gauge indications will be read in the display center in location 000 to location 015.
197
Fields 100 and 101 are the same and are locked Fields 100 and 101 are unlocked (may be changed) 010: Reprogram the transmission ECM 1xx: the 1ist1 shows that 100 and 101 are diffèrents
NOTE : In the fields 100 and 101 new codes ending per 02 may be shown. This is for future uses.
Centre de formation
4A.25.00
