21C SERIE WHEEL LOADERS TRAINING MANUAL PROGRAMMING THE INFORMATION CENTER Données et champs correspondants Numéro du champ
Donnée
Etat du code
039
Current Status Master Indicator (Red)
00 = Off 01 = On
040
00 – Always
041
Current Status of Diagnostic Indicator (Book without the wrench - Operators Manual) Current Status Master Indicator (Yellow)
042 043
Master Reset Park Brake Switch Status
044
Redundant Brake Pressure Switch Closed = Normal Operation)
00 = switch closed 01 = switch oened
045
Service Brake Foot Switch Status
00 = switch openedt 01 = switch closed (closed actuated)
046
Pilot Lock-out Switch Status
00 = switch openedt 01 = switch closed (closed =control locked)
047
Spare
050
Minimum Gear SelectionRange
Range – 1st or2nd
051
Maximum Gear SelectionRange
Range – 2nd, 3irdet 4th
052 053
Minimum Gear Read Only Maximum Gear Read Only
055
Resettable faults
061 à 070
Service Hour Interval Selection #1 -10
071 à 090
Fault Code #1 Through Fault Code #10 Hour Code #1 Through Hour Code #10. Hour Codes Follow Fault Codes Respectively
091
1st Portion Of Transmission ECM Part Number (ZF)
5 digits from 0 to 9
092
2nd Portion Of Transmission ECM Part Number (ZF)
5 digits from 0 to 9
093 094 095
Cluster Software Revision Number Light Emitting Diode (LED) Duty Cycle Liquid Crystal Display (LCD) Duty Cycle
Centre de formation
00 = Off 01 = On 00 = Switch opened 01 =Switch closed (closed =brake engaged)
