4A - INFORMATION CENTER
21C SERIE WHEEL LOADERS TRAINING MANUAL PROGRAMMING THE INFORMATION CENTER
NOTE: To enter into the programming modes the key switch must be in the on position. To get into the programming of the instrument cluster you must Up count Programme perform the following steps: 1 Turn the key switch to the on position, however, do not start the machine. 2 Put the information center into the program mode by pressing the Program/Reset switch to the left. Down count Reset 3 Press the Up/Down Count switch to the right until the desired Display Field Number is on the display screen. 4 Push the Program/Reset Switch to the center position. This will display the current value stored in that program location. 5 Push the Up/Down Count switch to the right or left until the desired setting is obtained. 6 Push the Program/Reset switch to the right to store the value in the information center memory. This will also exit you from the programming mode. If you do not wish to change any of the values and only wish to read the information stored in that field display number location you do not need to press the Program/Reset switch to the Reset position, by going back to the Program position you can move to other display field number locations without starting at location 000. 7 Turn the key switch to the off position.
Display field number and description Field dnumber
Items
000 001 002 003 004 005 006 007 008 009 010 011 012 013 014 015 016
Engine Hoursr Engine Tachometer Speedometer in Miles Per Hour Speedometer in Kilometers Per Hour Engine Coolant Temperature in Degrees Celsius Engine Oil Pressure in Kilopascals Fuel Level in Percent of Fuel Tank Transmission Oil Temperature in Degrees Celsius Hydraulic Oil Temperature in Degrees Celsius Voltmeter Reading (Continuous) Gauge Display Selection Parking Brake Test / Clutch Calibration Information Center Light Setting ñ Work Lights Off. Information Center Light Setting ñ Work Lights On Voltmeter Reading at Key-on Alarm Status Coolant Level Status
017
Brake Pressure Status
018
Steering Pressure Status
019
Present Park Brake Output from Information Center Status
Centre de formation
Status
00 = Off 01 = On 00 = normal level 01 = low level 00 = Switch closed 01 =Switch opened opened = pressure OK 00 = Switch closed 01 = Switch opened opened = pressure OK 00 = Off 01 = On
4A.9.00
