21C SERIE WHEEL LOADERS TRAINING MANUAL INSTRUMENT CLUSTER LAYOUT Information center layout
Located directly between the engine coolant temperature gauge and the transmission temperature gauge is a large digital readout screen. This is the information center portion of the information cluster. This is where the operator will monitor critical machine functions, program the information center, and receive diagnostic information related to servicing the machine. At the top of the information center are five seven-segment LCD displays with a decimal point between the fourth and the fifth digit. Information Center Display
Here is a list of the functions that the operator can choose to see on the information center.: Hourmeter Displays the accumulated running time of the engine in hours and tenths of an hour with an hour glass symbol illuminated below the five digit display. Tachometer Displays the engine speed in revolutions per minute along with an ìn/minî symbol located below the five digit display. Speedometer Displays the ground speed in either kilometers per hour (km/h) or miles per hour (mph) along with either an ìkm/h or mphî symbol illuminated below the five digit display. Engine Coolant Temperature Displays the engine coolant temperature in Celsius with the engine coolant temperature bar graph flashing. Engine Oil pressure Displays the engine oil pressure in Kilopascals (Kpa) with the engine oil pressure bar graph flashing. Fuel Level Displays the fuel level in percent (%) remaining from a full tank with the fuel level bar graph flashing. Transmission Oil Temperature Displays the transmission oil temperature in Celsius with the transmission oil temperature bar graph flashing. Hydraulic Oil Temperature Displays the hydraulic oil temperature in Celsius with the hydraulic oil temperature bar graph flashing. Voltmeter Displays the electrical system voltage level in volts with the voltmeter bar graph flashing.
