CONTROLS/INSTRUMENTS/ACCESSORIES
!
WARNING: The operation must be carried out very slowly, over a short distance and only if it is really unavoidable.
Make sure that the shackles, chains and tackle are in perfect condition and strong enough to move the load. IMPORTANT: The load should always be kept in line with the undercarriage.
ROTATING BEACON (not supplied) CABLE
Template Name: OM_1_col Template Date: 1994_04_29
This cable is located behind the righ-hand rear cab upright and can be used for connecting a 24 V rotating beacon (not supplied).
Alt= to hide template information Alt+ to display template information
CD00E069
The towing holes, located at the front and the rear of the undercarriage, are intended for moving heavy objects of up to 10 tonnes maximum.
!
WARNING: This is a delicate maneuvrer which is always carried out at the risk of the user. The manufacturer’s warranty does not apply to any incidents or accidents which may occur during towing.
TRIM THIS EDGE
TOWING HOLES
CD01D028
77
