OPERATING INSTRUCTIONS
PDH0249
PDH0251
8. Bring the machine right to the front of the trailer and lower the attachment to the trailer bed. (Machine without attachment) TRIM THIS EDGE
6. When moving from the ramps onto the trailer bed, raise the boom slightly as soon as the attachment touches the trailer so as to bring the machine level and then move forward until the machine is resting entirely on the trailer. (Machine with attachment)
Alt= to hide template information Alt+ to display template information
(Machine with attachment)
(Machine with attachment)
PDH0250
7. When the machine is completely on the trailer, raise the attachment slightly and swing the upperstructure so as to bring the attachment round to the access ramp side.
9. Lock the upperstructure swing function. 10. Stop the engine, remove the starter switch key, raise the function cancellation lever (with the safety bar inward). 11. Make sure that all doors, hoods and access panels are correctly locked.
125
TRIM THIS EDGE RIGHT PAGE
Template Name: OM_1_col Template Date: 1994_04_29
CS99B519
8. Bring the machine right to the front of the trailer, swing the upperstructure 180°.
