ARTICULATED BOOM, HYDRAULIC HAMMER OR HIGH FLOW SELECTION MODE (optional) (CX210LC, CX210NLC and CX230) Consult your CASE Dealer to adjust the pressure and the flow necessary for using the optional accessory correctly. NOTE: When starting the engine, the articulated boom control is selected automatically.
Hammer configuration 3
TRIM THIS EDGE
4
2
1
CT04D010 CT04D009
1. Press the red key (1); the LED's (2) and (3) light up.
Alt= to hide template information Alt+ to display template information
IMPORTANT: When the hammer or high flow configurations are activated, it is not possible to use the boom articulation function.
2. Make sure that the valve located at the foot of the boom (to the right of the operator) is in the right position (open), a decal shows the position of the valve in accordance with the configuration. See "Decals" in the "Safety/Decals/Hand signals" section.
To return to the articulated boom configuration, press key (1) again; the LED (4) lights up and vice versa.
CD00E012
3. Use the pedal to start the hammer. See "Articulated boom control pedal" in the "Controls/Instruments/Accessories" section.
