OPERATING INSTRUCTIONS
Removal Template Name: OM_1_col Template Date: 1994_04_29
CD00H004
9. Make sure you can see that the bucket pin is correctly engaged in the latching hook.
CD00F033
TRIM THIS EDGE
1. Operate the dipper and bucket controls so that the dipper is practically vertical, sloping slightly towards the cab to release the safety device. Extend the bucket cylinder rod completely and maintain the hydraulic pressure so that the latching hook retracts.
Alt= to hide template information Alt+ to display template information
CD00F032
10. Operate the bucket control to retract the cylinder rod and allow the safety device to engage. IMPORTANT: If it is not possible to make a visual check sitting in the operator’s seat, get down from the machine and make sure that the tool is correctly connected with the safety device engaged.
1 CD00H001
2. Place the switch (1) in unlocking position. The audible alarm device will sound. See “Quick coupler locking and unlocking control switch” in the “Controls/Instruments/Accessories” Section.
108
