6. Raise the dipper and operate the bucket control to extend the bucket cylinder rod completely. 7. Place the switch (1) in the locked position. The audible alarm device will cease functionning. See “Quick coupler locking and unlocking control switch” in the “Controls/Instruments/Accessories” Section.
TRIM THIS EDGE
4. Operate the dipper control lever so as to bring the quick coupler hook (2) around the tool pin (3).
Alt= to hide template information Alt+ to display template information
OPERATING INSTRUCTIONS
CD00F036
CP00G001
8. Maintain the pressure in the bucket cylinder to allow the latching hook to close. Raise the attachment so you can see the bucket pin.
107
TRIM THIS EDGE RIGHT PAGE
Template Name: OM_1_col Template Date: 1994_04_29
5. Operate the bucket control lever so that the pin (3) is completely engaged in the latching hook (2).
