VanguardTM Twin-Cylinder OHV Liquid-Cooled Engine Section 4 - Engine Overhaul
6. Compress springs with needle nose pliers and insert spring behind brushes.
10. Install solenoid.
Fig. 117 7. Install brush retainer plate. 8. Assemble rubber seal to starter housing, Fig. 118. a. Be sure notch in rubber seal is inserted over tab on housing. BRUSH RETAINER
Fig. 119
CARBURETOR INSPECTION AND REPAIR Disassemble Carburetor 1. Remove fuel shut off solenoid with washer.
NOTCH TAB
2. Remove carburetor lower body screws and lift lower body straight away from upper body, Fig. 120. a. Discard gasket.
Fig. 118 9. Install end cap, Fig. 119. a. Torque through bolts to 70 in. lbs. (8.0 Nm).
Fig. 120
Page 51
