3. Then, carefully drive stud and puller nut the rest of the way through seal.
Installing Water Pump Seal 1. Press or drive in new water pump seal until it bottoms with a 32 mm 12 point socket, Fig 100.
Fig. 98 4. Center the puller and stud in water pump seal and then rotate puller and stud 90°. 5. Assemble support driver , pilot nut , washer , and nut to puller stud and center assembly over water pump seal. 6. Hold hex head of puller stud and tighten nut until water pump seal is removed. 7. Thoroughly clean seal bearing surfaces.
Fig. 100
REPLACING STARTER SOLENOID 1. Remove nut and field coil wire from stud terminal. 2. Remove solenoid mounting nuts and solenoid. 3. Lift solenoid to disengage drive lever from plunger, Fig. 101.
NOTE: Hold starter in vertical position with drive housing side down when removing and installing solenoid.
Fig. 99
Fig. 101
