VanguardTM Twin-Cylinder OHV Liquid-Cooled Engine Section 4 - Engine Overhaul
3. Place a shop rag or short section of rubber fuel line under valves inside combustion chamber to hold valve in place while compressing spring.
2. Remove oil pick-up tube and screen assembly . a. Discard O-ring.
4. Install springs and valve spring retainers over valve stems.
Inspect Oil Pump
5. Temporarily, install rocker arm support screws in cylinder head.
Inspect pump drive gear for obvious wear or chipped teeth. Inspect pump rotors, housing and crankcase cover or sump for scoring or wear. Replace as required.
6. Compress valve spring with Tool #19347 and install split retainers, Fig. 92.
Assemble Oil Pump Lubricate outer rotor with oil and install in pump, Fig. 94.
Repeat procedure for other valves. Remove rocker arm screws.
Fig. 92
Fig. 94
OIL PUMP
1. Assemble oil pick-up tube and screen assembly with new O-ring to pump. a. Torque screw to 70 in. lbs. (8.0 Nm).
Disassemble Oil Pump 1. Remove two screws and oil pump gear baffle Fig. 93.
,
2. Install oil pump gear baffle, Fig. 95. a. Torque screw to 70 in. lbs. (8.0 Nm). 3. Assemble oil pump to crankcase cover with new O-rings, Fig. 95.
Fig. 93
Page 44
