VanguardTM Twin-Cylinder OHV Liquid-Cooled Engine Section 3 - Engine Disassembly
4. Remove governor control bracket and disconnect governor link , Fig. 45.
10. Remove air cleaner elbow screws , Fig. 47, and separate carburetor from intake elbow and air cleaner elbow.
Fig. 45
Fig. 47
5. Disconnect fuel shut off solenoid wire and remove ground wire. 6. Disconnect breather tube at air cleaner elbow Fig. 46. 7. Remove intake elbow screws
.
REMOVE STARTER
, 1. Remove two screws 48.
and starter motor, Fig.
8. Remove intake elbow and carburetor assembly. 9. Disconnect choke link at choke control.
Fig. 48 Fig. 46
Page 30
Remove Flywheel 1. Remove armatures assembly, Fig. 49.
and ground wire
