Removing the Subwoofer Module 1. See “Removing the Upper Cover” on page 70. 2. Remove the four securing screws from the Subwoofer Module.
Step Subwoofer Module
Size M2.5*4
Quantity
Screw Type
4
3. Grasp the cable by the end and guide it out of its housing as shown in the following images. IMPORTANT:The housing guides are hooked to hold the cable in place. Do not pull the cable to remove it or damage can occur.
