Removing the Switch Board 1. Remove the Switch Cover. See “Removing the Switch Cover” on page 62. 2. Lift the locking lever and remove the FFC cable on the left as shown.
3. Disconnect both cables on the right as shown.
4. Remove the two securing screws from the Switch Board and lift the board clear.
Step Switch Board
Chapter 3
Size M2*3 (NL)
Quantity
Screw Type
2
63
