Removing the Switch Cover CAUTION: Using tools to remove the Switch Cover may cause damage to the outer casing. It is recommended that only fingers are used to remove the Switch Cover. 1. Remove the Battery Pack. See “Removing the Battery Pack” on page 48. 2. Locate and remove the nine securing screws as shown.
Step
Size
Quantity
Switch Cover
M2.5*3 Blue Callout
4
Switch Cover
M2.5*6.5 Red Callout
5
Screw Type
3. Turn the computer over and open the LCD module fully to expose the Switch Cover. 4. Lift the Switch Cover up and away.
