Removing the Hard Disk Drive Module 1. Remove the Battery Pack. See “Removing the Battery Pack” on page 48. 2. Remove the HDD1 cover. See “Removing the Lower Covers” on page 50. 3. Remove the two securing screws.
Step HDD
Size M2*3
Quantity
Screw Type
2
4. Use the pull-tab to lift up the HDD module to remove.
NOTE: To prevent damage to device, avoid pressing down on it or placing heavy objects on top of it.
56
Chapter 3
