Information The Information screen displays a summary of your computer hardware information.
Information
Main
PhoenixBIOS Setup Utility Advanced Security Boot Power
Exit
CPU Type: CPU Speed:
AMD Turion(tm) Ultra Dual-Core Mobile ZM-82 2200 MHz
IDE Model Name: IDE Serial Number: IDE1 Model Name: IDE1 Serial Number: ATAPI Model Name: System BIOS Version: VGA BIOS Version: Serial Number: Asset Tag Number: Product Name: Manufacturer Name: UUID:
ST9250827AS 5RG01N2C
F1 Help ESC Exit
↑↓ Select Item ←→ Select Menu
Optiarc BD ROM BC-5500S V0.3103 nVidia 62.77.15.00.09 ZY50SK03C1815029FD2500
Acer 00B7B9A32AC4DC1198AE001E683E8E30
F5/F6 Change Values F9 Setup Defaults Enter SelectXSub-Menu F10 Save and Exit
NOTE: The system information is subject to different models. Parameter
30
Description
CPU Type
This field shows the CPU type and speed of the system.
CPU Speed
This field shows the speed of the CPU.
IDE Model Name
This field shows the model name of HDD installed on primary IDE master.
IDE Serial Number
This field displays the serial number of HDD installed on primary IDE master.
IDE1 Model Name
This field shows the model name of HDD installed on secondary IDE master.
IDE1 Serial Number
This field displays the serial number of HDD installed on secondary IDE master.
ATAPI Model Name
This field shows the model name of the Optical device installed in the system.
System BIOS Version
Displays system BIOS version.
VGA BIOS Version
This field displays the VGA firmware version of the system.
Serial Number
This field displays the serial number of this unit.
Asset Tag Number
This field displays the asset tag number of the system.
Product Name
This field shows product name of the system.
Manufacturer Name
This field displays the manufacturer of this system.
UUID Number
Universally Unique Identifier (UUID) is an identifier standard used in software construction, standardized by the Open Software Foundation (OSF) as part of the Distributed Computing Environment (DCE).
Chapter 2
