Bottom View
No.
Jumper
Description
No.
Jumper
Description
1
PJ1
DC JACK
15
CN30
SUBWOOFER CONN.
2
CN11
RJ5 CONN.
16
U34
CIR
3
CN12
DOCKING CONN.
17
CN28
2nd HDD CONN.
4
CN14
FAN CONN.
18
CN33
MINI CARD
5
CN15
CRT CONN.
19
VR1
VOLUME WHEEL
6
CN16
MXM CONN.
20
CN31
CARD READER
7
CN17
HDMI CONN.
21
CN26
1st HDD CONN.
8
CN18
USB CONN.
22
CN19
ODD CONN.
9
CN20
USB CONN.
23
J1
SODIMM CONN.
10
CN29
S/PDIF JACK
24
PCN1
BATTERY CONN.
11
CN25
MIC CONN.
25
T90
CPU SOCKET
12
CN23
LINE-IN CONN.
26
CN13
RTC SOKET
27
U24
NVIDIA MCP7
13
CN27
SPEAKER CONN.
14
CN24
MIC CONN.
