Removing the LCD Bezel 1. Remove the LCD Module. See “Removing the LCD Module” on page 68. 2. Remove the six rubber covers and screws.
Step LCD Bezel
Size M2.5*6.5
Quantity
Screw Type
6
3. Starting from the inside edges, pry the inside of the bezel upwards from the panel. Continue moving left until the bezel is removed. If necessary, use a plastic pry to release the corners of the bezel.
