Tires
and
Wheels
Wheels and Tires
Wheel Specifications (Factory) Wheel Type
Location
Size
Offset
Front
8.0J x 19
1.575" 40 mm
Rear
8.0J x 19
1.575" 40 mm
21" - Silver (standard)
Front
8.5J x 21
1.575" 40 mm
21" - Grey (standard)
Rear
8.5J x 21
1.575" 40 mm
21" - Silver and Grey (optional) Performance Plus vehicles
Rear
9.0J x 21
1.575" 40 mm
19"
Lug Nut Torque
129 lb. ft (175 Nm)
Lug Nut Socket Size
21 mm
Note: For instructions on how to jack/lift Model S, see Jacking and Lifting on page 167.
Tire Specifications (Factory) Tire Type
Location
Size
19" wheels
All
P245/45R19
21" wheels
Front Rear
P245/35R21 P265/35R21*
*On a Performance All-Wheel Drive vehicle, the width of the rear tires may vary depending on date of manufacture. Some vehicles may be equipped with P245/35R21 tires on both front and rear. Tire pressures vary depending on the type of tires fitted. Refer to the tire pressures printed on the Tire and Loading Information label. This label is located on the center door pillar and is visible when the driver’s door is open (see Maintaining Tire Pressures on page 153). Winter tires can be purchased from a Tesla store.
Specifications
177
