DRIVE OF AGRICULTURAL MACHINERY
F13BN023
F13BN024
ENGAGING REAR PTO SHAFT The number of PTO shaft revolutions is dependent on the number of engine revolutions With engine running: 1. Select applicable operation mode by standard and economic PTO shaft revolutions preselection lever. 2. Select applicable revolutions by switch of selection of rear PTO shaft (2) revolutions 3. Rear PTO shaft is set into operation by switching the switch of rear PTO shaft (3) If the aggregated machine allows it, engage the rear PTO shaft with minimum revolutions of 1500 rpm.
85
