MAINTENANCE INSTRUCTIONS
F_02_111
F11N03
AFTER DRAINING OIL 1. Clean the magnet (it is part of the lid) and the strainer element of the suctioning filter (2) 2. Replace the filter element (1) Tighten the cleaner bowl screw by hand, do not use any tools 3. After cleaning screw all the drain screws back on. 4. Fill oil (approx. 40 litres), start the engine and let it run for approx. 2 minutes 5. After stopping of the engine and stabilization of the oil level in the gearbox check its quantity and fill up oil to the upper edge of the dipstick tab or if increased filling is necessary, to the lower or upper mark of the dipstick.
REPLACEMENT OF THE TRANSMISSION OIL CLEANER ELEMENT WITH HYDRAULIC PUMP SUCTION FILTER The oil cleaner is placed on the left side of the gearbox. Before replacing the oil cleaner element, place a suitable vessel for dripping oil under the tractor. 1. Unscrew the body of the cleaner (1) 2. Replace the filtration element 3. Reassemble the body of the cleaner
