MAINTENANCE INSTRUCTIONS
FH12N016
FH12N015
CHECK AND REPLACEMENT OF OIL IN GEAR BOX DRAINING AND CHECKING HOLES 1. drain plug of oil from clutch box 2. drain plug of oil from gearbox 3. drain plug of oil from final drive housing 4. drain plug of oil from final drive housing box 5. drain plug of oil from final house driving box 6. Pouring opening for gear oil is placed in hydraulic mechanism housing. Accessible from the rear part of the tractor
CHECKING THE OIL IN GEARBOX The height of oil in gear box set is checked by oil level indicator which is placed at the right rear part of the gearbox behind the right hydraulic roller. A - Standard oil filling Carry out the check always with the engine stopped.
169
