MAINTENANCE INSTRUCTIONS
F_02_107
REPLACING THE FILTRATION ELEMENT OF THE HYDROSTATIC STEERING 1 - Dismantle the left rear side plate of the hood 2 - Place a suitable container under the hydrostatic steering tank 3 - Release the drain screw 4 - Drain oil from the tank
XF_02_141
5 - Unscrew the tank lid 6 - Replace the filtration element 7 - Install the new element
165
F_02_114
8 - Disconnect both the hoses from the working cylinder and together with the return hose insert their ends to a waste oil container. 9 - Start the engine and at the idle speed (max. 10 s) turn the steering wheel 2-3 times to both sides to push oil out of the steering unit and the pipes.
