Other controls
42
Heater Engine-independent (optional eqiupment)
Heater Engine-independent (optional eqiupment) NOTE! The heater unit is not permitted for operation using bio-Diesel. For additional information regarding safety instructions, instrumentation and maintenance, refer to operating instructions for the relevant engine. The controls are located on the left, next to the driver's seat on the cabin frame. The controls are located on the right, next to the driver’s seat on the cabin frame. Controls 1 Time 2 Pre-selection 3 Heating ON / OFF 4 Back 5 Advance 6 Memory display 7 Weekday or pre-selected day 8 Current time or pre-selected time 9 Temperature display 10 Operating indicator Temperature pre-selection - control range 10 to 30 °C (50 - 86 °F)
Heating operation without pre-selection with ignition “OFF” Switching on the heating – push button (3), control light comes on. – turn the rotary control (11) to pre-select the desired temperature. The operation indicator (10) and the heating duration indicator will be shown in the display. NOTE! The heating duration is preset to 120 minutes at the works. It can however be changed one-off or permanently as desired. Switching off the heating – push button (3), control light goes out. NOTE! For cooling purposes, the fan on the heating unit will run on for approx. 4 minutes after switching off.
