Specifications
Hydraulic system, specifications
Hydraulic system, specifications Hydraulic system specifications L30B Hydraulic pump
Double gear pump (pump 1)
Flow rate
55 l/min (14.5 US gal/min)
at engine speed
2300 rpm
Pressure relief setting
23 MPa (230 bar) (3335 psi)
Tipping cylinder
1 double acting tipping cylinder
Lift cylinder
2 double acting lift cylinders
Secondary pressure relief valves (shock) Lifting cylinder (piston area)
32 MPa (320 bar) (4060 psi)
Tipping cylinder (piston rod and piston end)
28 MPa (280 bar) (4640 psi)
Special hydraulics
20 MPa (200 bar) (2900 psi)
Loading times: Lifting time (under load)
6.5 sec.
Lowering time (empty)
3.5 sec.
Tipping time
1.5 sec.
Hydraulic system specifications L35B Hydraulic pump
Gear pump
Flow rate
73 l/min (19.2 US gal/min)
at engine speed
2600 rpm
Pressure relief setting
25 MPa (250 bar) (3625 psi)
Tipping cylinder
1 double acting tipping cylinder
Lift cylinder
2 double acting lift cylinders
Secondary pressure relief valves (shock) Lifting cylinder (piston area)
32 MPa (320 bar) (4060 psi)
Tipping cylinder (piston rod and piston end)
28 MPa (280 bar) (4640 psi)
Machine series 189 Tipping cylinder (piston rod)
15 MPa (150 bar) (2175 psi)
Special hydraulics
20 MPa (200 bar) (2900 psi)
Loading time machines series: 186, 187, 188 Lifting time (under load)
5.5 sec.
Lowering time (empty)
3.5 sec.
Tipping time
1.2 sec.
Loading time machines series: 189 Lifting time (under load)
6.5 sec.
Lowering time (empty)
4.0 sec.
Tipping time
2.0 sec.
149
