Presentation
Product plates
11
Product plates The following illustrations and descriptions show the identification plates on the machine. When ordering spare parts or in case of enquiries by phone and in correspondence model designations and product identification number must be specified.
5 4
1 /2
3 1032622
1
Product Identification plate (PIN) Contains name and adress of manufacturer.model designation, product identification number (serial-no), machine wight, enginepower, year of manufacture, year of delivert as well as CE-sign (only in EU/ EEA countries). The product identification number (seriel-no) is additional staped on the right side of the front frame.
4
Engine identification plate Contains design, engine number as well as performence data. The engine serial number is additionally stamped on the crankcase.
2
Additional type plate (only for Germany) 5 Contains name and address of manufacturer. model designation, vehicle identification number (serial-no), perm.total weight, perm.front/rear axle load and year of manufacture.
Cab the manufacturingnumber of the cabin is stamped on the left hand roof column.
3
ROPS/FOPS plate This plate is located on the left behind the side trim. It includes model designation, ROPS/FOPS number and max. machine weight.
