Hardware Specifications and Configurations Processor Item
Specification
CPU type
Intel® Pentium® M YonahProcessor dual core at 1.66~2.16 GHz Intel® Pentium® M Yonah Processor single core at 1.66~1.83 GHz Intel® Celeron® M Yonah Processosr at 1.66~1.83 GHz
CPU package
uFCPGA
CPU core voltage
Depend on DVI
CPU I/O voltage
VCCA 1.5V VCCP 1.05V
System Board Major Chips Item System core logic
Controller Intel® 945GM/ICH7M Intel® 945PM/ICH7M Intel® 940GML+ICH7M
Super I/O controller
N/A
Audio controller
Azalia Audio Controller ALC883
Video controller
ATI M54P/52P/52PG UMA
Hard disk drive controller
ICH7M
Keyboard controller
NS PC97551/541V
IrDA controller
N/A
DVI controller
N/A
PCMCIA/ card reader / 1394 controller
TI PCI7412
DDR-soDIMM controller
945PM/945GM/940GML
BIOS Item
Specification
BIOS vendor
Phoenix
BIOS Version
Phoenix First BIOS
BIOS ROM type
Flash ROM(SST39VF080)
BIOS ROM size
1MB
BIOS package
40 pins TSOP
BIOS password control
Set by setup manual
Item
Specification
Cache controller
Built-in CPU
Cache size
2 MB
1st level cache control
Always enabled
2nd level cache control
Always enabled
Cache scheme control
Always enabled
