Functions of and How to Use User Mode (TR-150-4/GR-150-1) Selecting Jib Mounted Condition WARNING If the jib mounted/dismounted state is set improperly, the AML does not function accurately. The crane operation in this condition could create hazard. The jib can be dismounted from the crane body when it is not used. The reduced mass of the crane body after jib removal will influence accuracy of the AML. Use this switch to set the jib mounted /dismounted state to the AML. [NOTICE] The key can be inserted in and removed from either “REMOVED” or “EQUIPPED” position. (1) “REMOVED” Select this position when the jib is dismounted. The jib removed indicator lamp will light up. (2) “EQUIPPED” Select this position when the jib is mounted. The jib removed indicator lamp will go off.
108
W301-0139E
