Assembly and Disassembly
TE RN
AL
[12] Use a wrench (8 mm) to loosen the hose band (12) on the inter cooler, and then remove the hose (13). • Use caps to cover the lines and hoses to prevent the entry of water, dust or dirt.
5(
E
CO US N F E ID O E F N TS TI M AL GL : F O OR BA T L H
[13] Use a wrench (19 mm) to remove the 6 bolts (14), and then remove the under cover (15). • Use caution when removing as the parts are heavy.
IN
Tightening torque for bolt installation: 68.6 ± 4.9 N•m
$(
[14] Prepare the waste oil can (16). • Drain the engine oil before removing the engine oil hose.
5(
7
BSM-06-11-010EN 7
