Assembly and Disassembly Engine Section
SH300-5
Assembly and Disassembly Removal and Installation of Engine Hood
AL
・ Be sure to stop the engine before beginning work. ・ Do not perform this operation in strong wind. Caution ・ Be sure to inspect the nylon sling and other lifting equipment before beginning work. ・ Do not stand or pass under the suspended load.
Items to prepare
TE RN
• Wrench (19 mm) • Nylon sling (with the required breaking load) • Liftcrane (with the required lifting capacity)
1. Removal of Engine Hood
CO US N F E ID O E F N TS TI M AL GL : F O OR BA T L H
E
IN
[1] Open the engine hood, and then remove the Matsuba pin (1) and the flat washer (2).
1
4(
BSM-06-11-010EN 1
