Procedures for Replacing Consumable Parts [7] Use a box wrench (17 mm) to loosen the alternator (5) tension bolt (10). [8] Remove the fan belt from the alternator (5).
5(
E
[9] While slowly turning the fan (11), pass the fan belt (12) over the 5 one at a time and remove it.
IN
TE RN
AL
CO US N F E ID O E F N TS TI M AL GL : F O OR BA T L H
BSM-06-10-010EN
5+
18 18
