Procedures for Replacing Consumable Parts Air Conditioner Belt Replacement Caution ・ Be sure to stop the engine before beginning work.
AL
Items to prepare • Wrench (19 mm)
TE RN
• Box wrench (14 mm) • Rags • Cleaning fluid
1. Air Conditioner Belt Removal
IN
[1] Use a wrench (19 mm) to remove the 4 bolts (2), and then remove the under cover (1).
CO US N F E ID O E F N TS TI M AL GL : F O OR BA T L H
E
Bolt tightening torque for installation: 68.6 ± 4.9 N•m
4(
[2] Use a box wrench (14 mm) to loosen the nut (3).
5(
[3] Use a box wrench (14 mm) to loosen the tension bolt (4).
5(
BSM-06-10-010EN
14 14
