OPERATING/INSTRUCTIONS
STATIONARY REAR PTO WORK According to the following instructions, use the Rear PTO for chipper, pump, or other stationary implements.
In this way, only the Rear PTO can be used. 1. Set the blocks at the tires. 2. Sit on the operator’s seat. 3. Apply the parking brake. 4. Make sure the all operating control levers are in “N“ or “OFF“. 5. Depress the clutch pedal and start the engine. 6. Shift the Rear PTO control lever to “ON”. 7. Adjust the proper engine speed for the Rear PTO work. 8. Leave the operator’s seat.
NOTE: I f you leave (stand up from) the seat when the Mid PTO is engaged, safety system will automatically shut down the engine.
If you leave the tractor with engine automatically shutting down, the battery is running down and possibly dead. To prevent it turn key switch to OFF position in case engine automatically shutting down.
MID PTO CONTROL LEVER REAR PTO CONTROL LEVER
56
