OPERATING/INSTRUCTIONS
HYDROSTATIC SPEED LOCK LEVER (Hydrostatic Drive Only) The speed ratio control pedal of hydrostatic drive has a speed lock lever. This lever is used to keep a constant forward speed without controlling the pedal. It can not be used for reverse speed. The lever is located under the instrument panel. Operate the speed lock lever as follows: 1. Determine forward speed as you need by pressing the speed ratio control pedal forward.
LOCK POSITION
2. Move the lock lever upward to lock the position of the pedal. (It can keep the forward speed constant). RELEASE POSITION
3. Remove your foot from the pedal. 4. To release the lock, move the lock lever downward.
NOTE: The speed ratio control pedal will return to neutral position and the tractor will stop If your foot is not on the pedal.
5. Increase of forward speed, speed ratio can be obtained to max. speed by pressing the pedal forward while the lock lever is in lock position. However, decrease of forward speed ratio or change to reverse speed can not be obtained, while the lock lever is in lock position.
6.To decrease forward speed ratio or change to reverse speed, put your foot on the pedal first, then release the lock lever. Control speed ratio or direction with the foot pedal.
NOTE:
1. The lock lever can not be released by pressing the brake pedal. 2. The lock lever can not be released by pressing the hydrostatic speed ratio control pedal. 3.Make sure to keep the lock lever in the off position when starting the tractor. 4.Return the lock lever to the off position when stopping the tractor.
50
